The Datasat AP25 is the product of years of innovation and experience in delivering digital sound for cinema. It delivers the precise reproduction of both digital and analog sources. It is the professional solution that is developed by sound engineers for the most realistic movie experience available in movie theaters worldwide.


Datasat AP25 Specifications

Digital Audio Decoders

Dolby
• Dolby AC3
DTS
• DTS Master Audio / DTS ES / DTS 5.1 / Neo:6

Signal Inputs

Digital Audio Inputs

• Channels: 16
• Connector: Two DB25 (Female) connectors (1-8) and (9-16)
• Digital Format: AES/EBU
• Sample Rates: 44.1kHz, 48kHz, 96 kHz and 192kHz

Other Digital Audio Inputs

• Connector: Two TOSLINK (optical S/PDIF) and 1 coaxial (S/PDIF)

Analog Audio Inputs

• Channels: 8 balanced that are fully routable as to output,
can be connected unbalanced
• Connector: DB25 (Female)
• Impedance: 10k ohms
• Sensitivity: 300mv rms

Other Analog Audio Inputs

• Channels: 2 stereo single ended and routable (non-sync) input pairs
• Connector: 4 RCA jacks
• Impedance: 10k ohms
• Sensitivity Adjustable: -16dBv to -4dBv

Microphone Input

• Single channel -68dBv to -8dBv input (XLR female connector) with switchable
+48V phantom power

HDMI Audio & Video Inputs

• Audio Channels: Up to 8 (PCM, DTS-HD Master Audio & Dolby AC3)
• Connectors: 5 HDMI connectors (ie: 4 switched as inputs and 1 as output –
Video passed thru)
• HDMI 1.3 compliant digital audio with video pass-thru

Signal Outputs:

Digital Audio Outputs

• Channels: 16 (fully routable as to input)
• Connector: Two DB25 (Male) connectors (1-8) and (9-16)
• Digital Format: AES/EBU
• Sample Rates: 48kHz, 96 kHz and 192kHz

Analog Audio Outputs

• Balanced (can be connected unbalanced or single ended)
– Channels: 16 (fully routable as to input), common mapping with

Digital Outputs

– Connectors: Two DB25 (Male) (1-8) and (9-16)
– Level: -10dBu with Fader at 7, +26dBu max (balanced)
• Connector: 1 single ended RCA output, channel-selectable to drive an
external monitor. Adjustable Levels, to 300mv rms
• Connector: 1 single ended RCA output, summed output for
Assistive Listening . – Fixed Level Out, 300mv rms
